数字微镜器件

3 x 0.69” DC2K 黑金属设备

自然分辨率

2048 x 1080 像素

机架

密封 DMD 和光学组件

灯泡

2.2千瓦，短弧氙气

光输出

9000流明

屏幕尺寸

宽度可达10米/33英寸（屏幕增益1.2 @ 14ftl）

对比度

1850:1

主镜头

Fully motorized
1.2 - 1.7
1.34 - 1.9
1.5 - 2.15
1.7 - 2.55
2.0 - 3.9

控制I/O

3x Ethernet (RJ 45)
8x GPIO (DB 25)
3D interface
USB RS-232 interface (DB9)

集成式影院媒体处理

JPEG2000 2K & 4K DCI play-out
High Frame Rates 3D up to 120fps (60fps per eye)
JPEG 2000 bit-rates up to 625Mbps
Dual-channel color-correction
MPEG-2 (4:2:0 and 4:2:2 up to 60fps)
H.264**
2x DisplayPort 1.1a
2x 3G-SDI inputs*
1x multimedia HDMI 1.4a input (BluRay 3D / 4K)*
16x AES/EBU audio channels (2x RJ45)
8x GPI, 8x GPO (4x RJ45)
2x ETH for content connectivity & ingest
2x front-accessible USB 3.0 for fast ingest
2x front-accessible USB 2.0

* in testing
** software roadmap

集成存储

1.9TB effective storage (RAID-5)
3x 1TB Hot-swappable 2.5" hard-drives

Barco Web Commander

Projector Dashboard
Projector Control Board
Show Player/Editor/Scheduler
Automation, 3D, Ingest
TMS integration
Smart Projector Status
Via HTML5 web-browsers including iOS & Android tablets.

巴可公司通讯器

Projector installation & configuration
Projector update & maintenance

电力要求

220V

投影仪尺寸 (HxWxD)

325 x 626 x 925 mm
12.8 x 24.7 x 36.4 inch

投影仪重量

Recessed handles for easy carrying
56.5 kg / 125 lbs for carrying (lamp-house removed)
(66.5 kg / 147 lbs total weight)

环境温度

35°C/95°F（最大值）

选项

Barco CineMate App (iOS & Android) - free
ACS-2048
3D add-ons
Touch screen monitor, inc. Barco Commander & Communicator
Pedestal
CineCare Web
Auro 11.1 license**
Live 3D***
Ghostbusting***
** In testing
*** Software roadmap
